CSX325FJC24.000M-UT,CSX-325F,24MHz,3225mm,CITIZEN通信晶振

CSX325FJC24.000M-UT,CSX-325F,24MHz,3225mm,CITIZEN通信晶振，日本进口晶振，Citizen晶振，西铁城晶振，型号：CSX-325F系列，编码为：CSX325FJC24.000M-UT，频率：24MHz，稳定性：±100ppm，工作温度范围：-20℃至+70℃，电压：3.3V，小体积晶振尺寸：3.2x2.5mm，四脚贴片晶振，有源晶振，石英晶振，SMD晶振，XO石英晶体振荡器，石英水晶振动子。具有超小型晶振，轻薄型晶振，高品质晶振，高性能晶振等特点。适用于各种应用，例如：通讯设备晶振，AV设备应用、汽车电子晶振，测量仪器晶振，无线蓝牙晶振，安防设备晶振等应用。

CSX325FJC24.000M-UT,CSX-325F,24MHz,3225mm,CITIZEN通信晶振，产品特点：

超轻重量和超小型尺寸

高密度SMD型石英晶振

低电流消耗

自动安装和可回流式

20180421171456_6296统一

CSX325FJC24.000M-UT,CSX-325F,24MHz,3225mm,CITIZEN通信晶振,参数表

Item
Frequency Range

Model

CSX-325F（@）(*)
24MHz

Supply Voltag(@)

H : Vdd＝2.5V±0.1V

J : Vdd＝3.3V±0.1V

Frequency Stability(*)

B : ±50ppm, C : ±100ppm, E : ±50ppm（－40℃~+85℃), F : ±100ppm（－40℃~+85℃)

Operating Temperature Range

-20℃~+70℃(-40℃~+85℃)

Storage Temperature Range

-55℃~+125℃

Current consumption（No load）

5mA Max.（＜30.0MHz）/ 7mA Max.（＜54.0MHz）

DutyCMOS level（1/2 Vdd）

40～60%

Output Voltage

VOH

VOL

0.8Vdd Min.

0.2Vdd Max.

Output Load

CMOS 15pF Max.

Rise and Fall Time0.2Vdd⇔0.8Vdd

10 nsec Max.

Start-up time

10 msec Max.

Aging (first year)

±2ppm / year Max.

20181130160053_3983统一

CSX325FJC24.000M-UT,CSX-325F,24MHz,3225mm,CITIZEN通信晶振,尺寸图

品牌	晶振编码	型号	频率	类型	电源电压
Citizen晶振	CSX325FJC12.500M-UT	CSX-325F	12.5MHz	XO (Standard)	3.3V
Citizen晶振	CSX325FJC13.500M-UT	CSX-325F	13.5MHz	XO (Standard)	3.3V
Citizen晶振	CSX325FJC20.000M-UT	CSX-325F	20MHz	XO (Standard)	3.3V
Citizen晶振	CSX325FJC22.000M-UT	CSX-325F	22MHz	XO (Standard)	3.3V
Citizen晶振	CSX325FJC24.000M-UT	CSX-325F	24MHz	XO (Standard)	3.3V
Citizen晶振	CSX325FJC25.000M-UT	CSX-325F	25MHz	XO (Standard)	3.3V
Citizen晶振	CSX325FJC27.000M-UT	CSX-325F	27MHz	XO (Standard)	3.3V
Citizen晶振	CSX325FJC40.000M-UT	CSX-325F	40MHz	XO (Standard)	3.3V
Citizen晶振	CSX325FJC44.000M-UT	CSX-325F	44MHz	XO (Standard)	3.3V
Citizen晶振	CSX325FJC48.000M-UT	CSX-325F	48MHz	XO (Standard)	3.3V
Citizen晶振	CSX325FHC12.500M-UT	CSX-325F	12.5MHz	XO (Standard)	2.5V
Citizen晶振	CSX325FHC13.500M-UT	CSX-325F	13.5MHz	XO (Standard)	2.5V
Citizen晶振	CSX325FHC20.000M-UT	CSX-325F	20MHz	XO (Standard)	2.5V
Citizen晶振	CSX325FHC22.000M-UT	CSX-325F	22MHz	XO (Standard)	2.5V
Citizen晶振	CSX325FHC24.000M-UT	CSX-325F	24MHz	XO (Standard)	2.5V
Citizen晶振	CSX325FHC25.000M-UT	CSX-325F	25MHz	XO (Standard)	2.5V
Citizen晶振	CSX325FHC27.000M-UT	CSX-325F	27MHz	XO (Standard)	2.5V
Citizen晶振	CSX325FHC40.000M-UT	CSX-325F	40MHz	XO (Standard)	2.5V
Citizen晶振	CSX325FHC44.000M-UT	CSX-325F	44MHz	XO (Standard)	2.5V
Citizen晶振	CSX325FHC48.000M-UT	CSX-325F	48MHz	XO (Standard)	2.5V
西铁城晶振	CSX-252FAE24576000T	CSX-252F	24.576MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE40000000T	CSX-252F	40MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE20000000T	CSX-252F	20MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE6000000T	CSX-252F	6MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE33300000T	CSX-252F	33.3MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE10000000T	CSX-252F	10MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE48000000T	CSX-252F	48MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE27000000T	CSX-252F	27MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE12000000T	CSX-252F	12MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE25000000T	CSX-252F	25MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE35000000T	CSX-252F	35MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE16934400T	CSX-252F	16.9344MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE30720000T	CSX-252F	30.72MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE13000000T	CSX-252F	13MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE50000000T	CSX-252F	50MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE16000000T	CSX-252F	16MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE24000000T	CSX-252F	24MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE26000000T	CSX-252F	26MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAE33000000T	CSX-252F	33MHz	XO (Standard)	1.8 V ~ 3.3 V
Citizen晶振	CSX-252FAP32768T	CSX-252F	32.768kHz	XO (Standard)	1.8 V ~ 3.3 V
