低损耗的无源晶振Q22FA2380021616用于蓝牙灯控模块
低损耗的无源晶振Q22FA2380021616用于蓝牙灯控模块，在这个花样多彩的电子行业，难以从众多企业中脱颖而出，爱普生的杰出恰如其分说明，只要足够努力拼搏，总会吸引更多美好的事物或人，通过自身的一路成长，敢于与困难相互斗争，敢于不断挑战自我的极限，使得快速打磨大量优质的石英晶振产品，并得到用户的认可。
                                                                                                                                                               产品编码
|
 尺寸
|
 型号
|
 爱普生晶振 |
 负载
|
 Freq.tol. @+25°C
|
 Freq.tol./Temp.range
|
 Temperature range
|
 ESR [Max]
|
| Q22FA2380015616 | 3.2 x 2.5 x 0.7mm | FA-238 | 24.576000 MHz | 10 pF | +/-50 ppm | +/-30 ppm | -20 to +70 °C | ≤ 60 Ω |
| Q22FA2380016516 | 3.2 x 2.5 x 0.7mm | FA-238 | 25.000000 MHz | 12 pF | +/-30 ppm | +/-30 ppm | -20 to +70 °C | ≤ 50 Ω |
| Q22FA2380017016 | 3.2 x 2.5 x 0.7mm | FA-238 | 20.000000 MHz | 20 pF | +/-50 ppm | +/-30 ppm | -20 to +70 °C | ≤ 60 Ω |
| Q22FA2380017916 | 3.2 x 2.5 x 0.7mm | FA-238 | 16.000000 MHz | 12.5 pF | +/-50 ppm | +/-30 ppm | -20 to +70 °C | ≤ 80 Ω |
| Q22FA2380019016 | 3.2 x 2.5 x 0.7mm | FA-238 | 24.576000 MHz | 8 pF | +/-50 ppm | +/-30 ppm | -20 to +70 °C | ≤ 60 Ω |
| Q22FA2380019816 | 3.2 x 2.5 x 0.7mm | FA-238 | 24.576000 MHz | 7 pF | +/-50 ppm | +/-30 ppm | -20 to +70 °C | ≤ 60 Ω |
| Q22FA2380020516 | 3.2 x 2.5 x 0.7mm | FA-238 | 19.200000 MHz | 10 pF | +/-50 ppm | +/-30 ppm | -20 to +70 °C | ≤ 80 Ω |
| Q22FA2380021616 | 3.2 x 2.5 x 0.7mm | FA-238 | 16.000000 MHz | 12 pF | +/-30 ppm | +/-30 ppm | -20 to +70 °C | ≤ 80 Ω |
| Q22FA2380023816 | 3.2 x 2.5 x 0.7mm | FA-238 | 24.000000 MHz | 20 pF | +/-30 ppm | +/-30 ppm | -20 to +70 °C | ≤ 60 Ω |
| Q22FA2380024016 | 3.2 x 2.5 x 0.7mm | FA-238 | 24.000000 MHz | 30 pF | +/-50 ppm | +/-30 ppm | -20 to +70 °C | ≤ 60 Ω |
| Q22FA2380024416 | 3.2 x 2.5 x 0.7mm | FA-238 | 48.000000 MHz | 20 pF | +/-30 ppm | +/-30 ppm | -20 to +70 °C | ≤ 40 Ω |
| Q22FA2380024516 | 3.2 x 2.5 x 0.7mm | FA-238 | 24.000000 MHz | 30 pF | +/-30 ppm | +/-30 ppm | -20 to +70 °C | ≤ 60 Ω |
| Q22FA2380025116 | 3.2 x 2.5 x 0.7mm | FA-238 | 36.864000 MHz | 8 pF | +/-50 ppm | +/-30 ppm | -20 to +70 °C | ≤ 40 Ω |
| Q22FA2380026316 | 3.2 x 2.5 x 0.7mm | FA-238 | 16.000000 MHz | 9 pF | +/-15 ppm | +/-30 ppm | -20 to +70 °C | ≤ 80 Ω |
| Q22FA2380026416 | 3.2 x 2.5 x 0.7mm | FA-238 | 20.000000 MHz | 10 pF | +/-50 ppm | +/-30 ppm | -20 to +70 °C | ≤ 60 Ω |
| Q22FA2380026916 | 3.2 x 2.5 x 0.7mm | FA-238 | 27.000000 MHz | 9 pF | +/-50 ppm | +/-30 ppm | -20 to +70 °C | ≤ 50 Ω |
| Q22FA2380029116 | 3.2 x 2.5 x 0.7mm | FA-238 | 27.000000 MHz | 7 pF | +/-50 ppm | +/-30 ppm | -20 to +70 °C | ≤ 50 Ω |
| Q22FA2380030516 | 3.2 x 2.5 x 0.7mm | FA-238 | 24.576000 MHz | 16 pF | +/-50 ppm | +/-30 ppm | -20 to +70 °C | ≤ 60 Ω |
| Q22FA2380031216 | 3.2 x 2.5 x 0.7mm | FA-238 | 28.636360 MHz | 16 pF | +/-50 ppm | +/-30 ppm | -20 to +70 °C | ≤ 50 Ω |
| Q22FA2380032216 | 3.2 x 2.5 x 0.7mm | FA-238 | 20.000000 MHz | 12.5 pF | +/-30 ppm | +/-30 ppm | -20 to +70 °C | ≤ 60 Ω |
爱普生品牌系列千赫子的石英贴片晶振,目前占据了中国市场进口晶25％的份额,品牌质量,货期,品种,品质是广大用户有目共睹,从MC-146晶振最早期从MP4,MP3收音机模块启用开始,在到国内外各大知名品牌手机,最后应用到国内山寨手机市场,几乎占据80％的手机行业晶振类别,产品本身特点是体积小,耐高温,稳定性能高,排带包装,应用自动贴片方便.
